Hikvision DS-KH6320Y-WTE2 – IP Video Intercom Indoor Station, 7" IPS, 2-Wire, Wi-Fi

The Hikvision DS-KH6320Y-WTE2 is a professional 2-wire IP indoor station for video intercom systems. It enables two-way audio and video communication with door stations, live viewing of IP cameras, remote door unlocking, and integration with alarm and elevator control systems – all from a single 7-inch touchscreen or via the Hik-Connect app. Power and data are transmitted over just two wires, greatly simplifying installation and making full use of existing cabling infrastructure.

Key features

• Display: 7-inch capacitive TFT IPS touchscreen, 1024 × 600 resolution
• Architecture: 2-wire IP – power, audio, video and control signals over a single wire pair; no PC required for commissioning
• Wireless: Built-in Wi-Fi 802.11 b/g/n (2.4 GHz)
• Mobile control: Hik-Connect app (iOS/Android) – remote call answering, door unlocking and live view
• Audio: Built-in omnidirectional microphone with noise suppression and echo cancellation; built-in loudspeaker; G.711 U/A, G.722.1; 64 Kbps
• Alarm interfaces: 8 alarm inputs, 2 alarm outputs, 1 × RS-485
• Lock control: 2 relays (max. 30 VDC, 0.3 A)
• Capacity: Up to 17 IP door stations; storage for 200 captured images and 200 alarm records (with microSD card)
• Memory card: microSD slot, up to 128 GB
• System: Embedded Linux; 128 MB RAM, 32 MB ROM
• Power consumption: ≤ 6 W; powered via 2-wire distributor (DS-KAD704Y or DS-KAD706Y series, sold separately)
• Operating temperature: –10 °C to +50 °C
• Integrations: CCTV systems, elevator control, alarm systems; iVMS-4200 client software
• Languages: Slovenian and 40+ other languages supported

The DS-KH6320Y-WTE2 is an ideal solution for residential and commercial buildings requiring a reliable, easy-to-install intercom system with advanced alarm and access control capabilities.
